DC microwave motion sensor

Model

YW303

Operating voltage

DC 24V/ 10A

Output

DIM 0~10V

HF system

5.8GHz±75MHz,

Power consumption

≤0.5W(standby)

Detection Area

8m/6m/4m/2m (as request)

Motion detection

0.5~3m/s

Stand-by dimming level

0% / 10% (as request)

Detection angle

150 °(wall installation) 360 °(ceiling installation)

Hold time

1min / 10min

Size

75*25*13mm (L*W*H)

IP rating

IP20

Operation temperature

-20℃~60℃

Life time

50,000 hours
